Description Attention please!!! Please kindly read the following tips before purchasing. 1. The transaction of large machinery cannot be completed on AliExpress. 2. The express fee on AliExpress has no reference value, please ignore it. We ship by sea instead of express, please contact us to get the freight to your sea port. 3. If any problem please feel free to contact with us. Whatsapp 86 18656680921 Email [email protected] Main Features: 1. Spindle unit BT40 by KENTURN Brand with 8000rpm; 2. Precious Ball Screw by PMI or HIWIN Brand; 3. Disk type ATC 24pcs by OSHIMA Brand; 4. FANUC 0i MF(5)as standard CNC controller system, and Mitsubishi System or Siemens system as optional selection.; 5. Optimized Structure of Heavy Rail Linear Guide. 6. Suitable for machining parts of automobile, mold industry and so on. Specification VMC1160L Worktable Worktable size (L×W) 1200×600mm T-slots size (N×W×D) 5-18x100mm Travel X/Y/Z axis travel 1100/600/600mm Machining range Distance from spindle center to column 650mm Distance from spindle nose to worktable surface 120-720mm Spindle Spindle taper BT40 Spindle power 11kw Max. spindle speed 8000rpm Feed Max. feed speed 10m/min Rapid feed speed (X/Y/Z) 24/24/20m/min Ball screw (diameter lead) X/Y/Z axis ball screw 4012 Tool magazine Tool magazine capacity 24T Max. length of tool 300mm Tool change time 1.5s Positioning accuracy (National standard) Positioning accuracy (X/Y/Z) ±0.005mm Re-positioning accuracy(X/Y/Z) ±0.003mm Machine dimension L×W×H 3350×2300×2550mm Machine weight Max. loading of worktable 800kg Machine weight 6200kg FAQ Q1: How is the warranty?A1: Warranty time is 13 months after BL date.Q2: Can we visit your factory before order?A2: Sure. All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.Q3: Do you have a stock?A3: Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.Q4: What’s the MOQ?A4: One set only.Q5: How about your quality?A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.Q6: Do you have professional engineers?A6: Yes, we have professional engineers and designers. We can provide OEM services.Q7: Can you provide customized machines?A7: Yes, we can design and manufacture according to your specific requirements. Attachments (PDF)
